Product Specifications
- Sensitivity (2.83 volts @ 1 meter)
- 89dB
- Low-Frequency Transducer (Woofer)
- 8 inch Titanium-laminate cone with rubber surround
- High-Frequency Transducer (Tweeter)
- 1 inch (25mm) Titanium laminate dome with EOS waveguide and swivel mount
- Recommended Amplifier Power (RMS)
- 100 Watts
- Frequency Response
- 30Hz – 20kHz (-10dB)
- Crossover Frequency(ies)
- 2.4kHz
- MSRP U.S.
- $549.95 per pair
- Plate Size (W x H)
- 10-1/8 inch x 13-1/8 inch (257mm x 333mm)
- Mounting Depth
- 4 inch (102mm)
- Cutout Dimensions
- 8-7/8 inch x 11-13/16 inch (225mm x 300mm)
