JBL Bar 1000MK2
7.1.4 channel soundbar system with detachable surround speakers, MultiBeam 3.0™, Dolby Atmos® and DTS:X®
Verkauft von 2025 bis jetzt
Erste Schritte mit deinem JBL Bar 1000MK2
Kurzanleitung
Starte im Handumdrehen mit unserer leicht verständlichen Kurzanleitung
Registriere dein Produkt.
Besitzt du dieses Produkt? Registriere es hier! Und nimm deine Garantie oder deinen Service einfach in Anspruch
Jetzt registrierenSchnellstartleitfaden & Downloads
Produktdetails
- Sound system
- 7.1.4 channel
- Power supply
- 100 - 240V AC, ~ 50/60Hz
- Total speaker power output* (Max. @THD 1%)
- 480 W RMS
- Soundbar output power** (Max. @THD 1%)
- 250 W RMS
- Surround speaker output power*** (Max. @THD 1%)
- 2x 40 W RMS
- Subwoofer output power**** (Max. @THD 1%)
- 150 W RMS
- Soundbar transducer
- 6x (44x80)mm racetrack drivers, 2x 1" (25mm) tweeters, 2x 2.75" (70mm) up-firing full-range drivers
- Surround speaker transducer
- 2x (44x90)mm racetrack drivers, 2x 2.75" (70mm) up-firing full-range drivers
- Subwoofer transducer
- 10” (260mm)
- Networked standby power
- < 2.0 W
- Operating temperature
- 0°C - 45 °C
- Lithium battery
- 3.635V, 6600mAh
- Detachable surround speaker playtime
- up to 10 hours (may vary according to content type and volume level)
- Frequency response
- 33Hz - 20kHz (-6dB)
- Audio inputs
- Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
- Total soundbar dimensions (W x H x D)
- 1203 x 52x 128mm / 47.4" x 2.0" x 5.0"
- Soundbar dimensions (W x H x D)
- 854 x 52 x 128mm / 33.6" x 2.0" x 5.0"
- Detachable surround speaker dimensions (each) (W x H x D)
- 189x 52 x 128mm / 7.4" x 2.0" x 5.0"
- Subwoofer dimensions (W x H x D):
- 325 x 400 x 325 mm / 12.8" x 15.7" x 12.8"
- Soundbar weight
- 5.5kg / 12.1 lbs
- Detachable surround speaker weight (each)
- 0.9 kg / 2 lbs
- Subwoofer weight
- 9.1 kg / 20 lbs
- Packaging dimensions (W x H x D)
- 980 x 398 x 495 mm / 38.58" x 15.67" x 19.49"
- Packaging Weight
- 22.6kg / 49.8lbs (EMEA/UK/AU/NZ);19.9kg / 44.4lbs (Others)
- USB port
- Type A
- USB rating
- 5V DC, 0.5A
- Supporting file formats
- mp3
- MP3 codec
- MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
- MP3 sampling rate
- 16 - 48 kHz
- MP3 bitrate
- 80 - 320 kbps
- Bluetooth version
- v5.3
- Bluetooth profile
- A2DP v1.3, AVRCP v1.5
- Bluetooth transmitter frequency range
- 2400 MHz – 2483.5 MHz
- Bluetooth transmitter power
- <15 dBm (EIRP)
- Wi-Fi network
- IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
- 2.4G Wi-Fi transmitter frequency range
- 2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
- 2.4G Wi-Fi transmitter power
- < 20 dBm (EIRP)
- 5G Wi-Fi transmitter frequency range
- 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
- 5G Wi-Fi transmitter power
- 5.15 - 5.25GHz <23dBm,
- 5.25 - 5.35GHz & 5.470 - 5.725GHz <20dBm, 5.725 - 5.825GHz <14dBm (EIRP)
- 2.4G wireless transmitter frequency range
- 2406 - 2474MHz
- 2.4G wireless transmitter power
- <10dBm (EIRP)
- Note
- Band 5.6 - 5.64 GHz will be disabled when shipped to Australia / New Zealand.
- HDMI video input
- 3
- HDMI video output (with Enhanced Audio Return Channel, eARC)
- 1
- HDMI HDCP version
- 2.3
- HDR pass through
- HDR10+, Dolby Vision
Get real spatial sound in seconds
Real spatial sound—the kind that fills your space from floor to ceiling with true Dolby Atmos® and DTS:X height effects—can be yours in seconds. Just pick up the detachable wireless speakers from either end of the JBL BAR 1000MK2 soundbar and place them behind where you're sitting. That's it. While you're pulled into the center of the action, you'll enjoy deep, punchy bass from a 10" subwoofer and MultiBeam™ 3.0 for the widest, most cinematic soundstage. If you need to step out of the room while you're catching up with your favorite video podcast or enjoying your go-to streaming playlist on your TV, take one of the wireless speakers along and you won't have to miss a thing. JBL can do this because our speakers are trusted in cinemas, recording studios, and concert halls. And this immersive sound experience works seamlessly with all TV brands. Enjoy the freedom of unbound cinematic sound.
Elevate your 3D surround sound experience with dynamic, immersive height. Four up-firing speakers in the soundbar and wireless rear speakers deliver true Dolby Atmos® sound. No extra wires. No power connections. Just lift the detachable surround speakers off the soundbar—you can do it with just one hand—and place them behind where you want to sit, instantly transforming them into a true surround sound setup. It's that simple. Whether you're binge-watching your new favorite show or hosting a movie night, the speakers' rechargeable long-lasting batteries mean you'll enjoy immersive, cinematic surround sound for hours. When you’re done, simply place them back on the soundbar to charge overnight.
Transform the way you watch, listen, and game. Experience new cinematic heights of sound. 480 watts of maximum output makes your spatial audio experience feel that much more powerful. Action movies get even more exciting with big, thundering bass from the 10" wireless subwoofer.
Plunge into theater-quality 3D spatial sound with true Dolby Atmos® and DTS:X. Shiver as spaceships fill the sky overhead. Feel explosions that rumble through your body. Experience music like you're right there in the recording studio.
Wherever you're sitting, you'll be in the middle of the action. Our MultiBeam™ 3.0 delivers a wide, cinema-like soundstage that makes every high-speed chase or epic fight scene come alive. The sound beams perfectly fill your room, delivering the most immersive, lifelike, and realistic sound reproduction.
Never miss a softly spoken line or a whispered plot twist. JBL's own PureVoice 2.0 automatically raises or optimizes the dialogue, based on both ambient sound in the scene and your soundbar's volume. So you'll always hear every word, clearly and consistently, in cinema-quality sound.
Hear all the subtleties in a film's sound mix, just like you would in the theater. From a creaking door to a faraway shout, experience every detail the way the filmmakers intended in a clear, balanced sound field, thanks to JBL's own advanced sound enhancement technology.
You don't want to miss any of the big game, even when you're in the kitchen making another batch of hot wings. Just bring one—or both, for stereo sound—of the detachable wireless speakers with you and you'll hear the same great movie-quality audio your family and guests are enjoying in the other room.
Enjoy your favorite shows or movies without disturbing others. Just put the wireless detachable speakers in front of you and use the JBL ONE app to turn on night listening. The soundbar and the subwoofer are automatically muted, while the speakers deliver an intimate high-quality audio experience just for one. Or two.
Every room is different. Your soundbar discovers how sound reflects off your walls and furniture. So it'll deliver the best 3D surround effects, tuned specifically for your space and with any TV.
Enjoy all your favorite music and podcasts in stunning high-definition sound. Choose from hundreds of online music streaming services through AirPlay, Google Cast, Spotify Connect, Tidal Connect, and Roon Ready.
Set up the soundbar using the JBL ONE app, then make it yours. Customize the sound your way with a precise equalizer, browse your favorite music apps, and get software upgrades for all the latest features, right from your couch.
No matter what brand your TV is, enjoy uncompressed Dolby Atmos surround sound through a single HDMI cable thanks to the HDMI eARC connection. The HDMI input connection also offers 4K video quality from a compatible video player or gaming console.
Play that song you're craving, even when you've got your hands full. Just link the soundbar to your device with built-in voice capabilities and control your music hands-free using Google Assistant or Siri.
When you're asleep, so is your soundbar. It uses less than 1 watt of power while in standby mode. That's about the same as your TV's remote control.
FAQs & How-To
1 Ergebnisse
-
- Stellen Sie sicher, dass Ihr Gerät mit der JBL One App während der ersten Einrichtung weniger als 10 m von der Soundbar entfernt ist.
- Stellen Sie sicher, dass Ihre JBL-Soundbar an die Stromversorgung angeschlossen ist und die Power-LED auf der BAR leuchtet.
- Ziehen Sie das Netzkabel ab, warten Sie 10 Sekunden, schließen Sie das Netzkabel wieder an und warten Sie, bis der Lautsprecher eingeschaltet ist.
- Positionieren Sie vorübergehend entweder die BAR oder den Router so, dass sie näher beieinander liegen. Wenn die Verbindung erfolgreich ist, ist der ursprüngliche Standort möglicherweise zu weit vom Router entfernt, um eine stabile Verbindung aufrechtzuerhalten.
- Versuchen Sie, ein anderes Gerät zu verwenden, auf dem die JBL ONE App installiert und das mit Ihrem Heimnetzwerk verbunden ist.
